Industrial devices display solutions

Home Industrial solutions Industrial devices display solutions

Description

Size TFT Part number Display Mode Color Resolution IC Outline

(mm)

 B/L Remark
7.00″ TFT800480-75-E Transmissive 16.7M 800 X RGB X 480 HX8264-E*1  HX8664-B*1 164.9*100*5.7 LED TN
7.00″ TFT800480-82-E Transmissive 16.7M 800 X RGB X 480 HX8264-D*1  HX8664-B*1 164.9*100*3.5 LED TN
7.00″ TFT7201280-41-V1 Transmissive 16.7M 720RGB X 1280 OTM1284A 92.1*167.9*2.51 LED IPS,MIPI
8″ TFT8001280-12 Transmissive 16.7M 800XRGBX1280 HX8260 114.6*184.1*2.5 LED MIPI,
8″ TFT8001280-7 Transmissive 16.7M 800 X RGB X 1280 HX8394-C 114.6*184.1*2.5 LED MIPI,IPS
8.4″ TFT800600-17 Transmissive 16.7M 800 x RGB X600 HX8677
HX8264		 189.75*149.4*4.8 LED NEED MOQ
10.1” TFT1024600-29 Transmissive 16.7M 1024 x RGB X600 ILI6150C/ILI5120 235*143*3.6 LED LVDS,TN
10.1” TFT8001280-17 Transmissive 16.7M 800 X RGB X1280 RM68200 142.9*228.5*2.49 LED MIPI interface
10.1” TFT19201200-4-V1 Transmissive 16.7M 1920 X RGB X1200 NT65902*4(D)
HX8677*2(R )		 227.92*148*2.295 LED MIPI/LVDS
10.4” TFT800600-5-E Transmissive 16.7M 800 X RGB X 600 HX8258-A*2+HX8677-A 246.3*179.5*13.7 LED TFT800600-4 LED BL , WITHOUT T/P,
11.0” TFT1280120-1-V2-E Transmissive 262K 1280 X RGB X120 HX8232-B*5
HX8655-C		 288.92*38.6*7.6 LED
15.6″ TFT19201080-8 Transmissive 262K 1920 X RGB X1080 / 359.5*206.5*3.2 LED Interface:eDP.IPS
